Full Overlap Boxes

Most slotted boxes are cut so each flap covers roughly half the panel, meeting its opposite number at the centerline. An FOL box is cut differently: every flap runs the full width of the box, so when the top and bottom are folded closed, one flap overlaps the other completely instead of stopping at the middle. The result is a panel with two full thicknesses of corrugated board everywhere, not just at the seam. It costs more board than a standard slotted case, which is exactly the trade a heavy or high-value shipment is worth making.

The double layer isn't just extra material — it changes how the box behaves under load. Corners and edges are where a corrugated case fails first, since that's where crush forces concentrate during handling and transit. With flaps overlapping the full panel, an FOL box carries reinforced coverage across those failure points, which translates directly into better stacking strength on a pallet or in a warehouse rack. We spec the board and flute grade to the load — single-wall for moderate weights, double-wall corrugated for denser or taller pallet stacks — so the extra strength shows up where the shipment actually needs it.

Full overlap boxes earn their keep on the freight lane, not the retail shelf. We build them most often for machine parts, metal components, glass, dense hardware, and other heavy or fragile items where a standard case would flex or blow out a corner under weight. The full-panel coverage also helps with irregular loads that don't distribute weight evenly — a common problem with mixed hardware or stacked components — since the reinforced top and bottom resist punching through at a single pressure point.

Every full overlap box on this page is, structurally, a slotted carton — the same family of corrugated case as an RSC, just built with the panels running the entire width instead of meeting at the center. Some buyers know the format as an overlap slotted carton rather than a full overlap box; both names point at the same double-thickness closure. Because the format is cut from the same corrugated board stock as our other slotted styles, FOL boxes scale from a single prototype to a full pallet run without changing vendors mid-order. Whether you call it an FOL case or a full-width slotted carton, the engineering question is the same: how much weight does the panel need to carry, and how long does it need to hold that weight without a corner giving out. Tell us the load and the haul, and we'll spec heavy-duty FOL boxes — or a lighter slotted carton style — to match.

The FOL box sits at the heavy-duty end of a spectrum that includes two other common slotted styles. A regular slotted container, or RSC, uses flaps that meet at the center rather than overlap — lighter on board, and perfectly adequate for standard e-commerce and retail freight, just not for a dense or fragile load that needs the extra corner protection. Half slotted containers skip the top flaps entirely and rely on a separate cap or pallet wrap, which suits oversized or palletized product but offers none of the built-in top protection an FOL box provides on its own. If your product needs a fully enclosed case that can take a beating in transit, FOL is usually the right call over either alternative.

We build every FOL box around the product's actual dimensions and weight rather than a stock size chart — the same standard we hold for all our custom boxes. Send us length, width, height, and typical load, and we'll prototype a dieline sized for a snug, supported fit. Board grade and flute profile get specced to the load at the same time, and printing runs from a single logo stamp to full exterior branding, all handled alongside die-cutting. For lighter shipments where full overlap coverage is more than the load needs, our custom product boxes team can help you find a more economical construction without giving up durability.

What is a full overlap box (FOL)? A full overlap box is a corrugated carton with flaps cut to the full width of the panel, so the top and bottom close with two complete layers of board instead of two flaps meeting at the center. That double coverage gives it more crush resistance and stacking strength than a standard slotted case.

What's the difference between FOL and RSC? A regular slotted container (RSC) has flaps that meet edge to edge at the center of the panel — one layer of coverage, less board, and enough strength for most standard freight. An FOL box uses full-width flaps that overlap completely, adding a second layer across the top and bottom for heavier, denser, or more fragile shipments that need the extra protection.

Are full overlap boxes a good fit for fragile or heavy items? Yes — that's the case they're built for. The double-panel coverage resists crushing and punch-through better than a single-flap closure, which is why we spec FOL construction most often for glass, metal parts, dense hardware, and other heavy or fragile freight.

Whether you're shipping a single prototype run or a full pallet order, we prototype and produce full overlap boxes and other corrugated boxes in New York City, from first sample to wholesale production — send your product information and we'll tell you whether an FOL case or something designed lighter is the ideal fit.
